Concentration display
|
LCD digital (full dot)
|
|
Detection target gas
|
Combustible gas (i-C4H10 / CH4 / H2 / C2H2), oxygen (O2), toxic gas (H2S[low concentration] / CO / NH3 / CI2 / O3 / HCI / SO2 / VOCs), carbon dioxide (CO2)
|
|
Detection method
|
Pump suction type
|
|
Suction flow rate
|
Minimum 0.75 L/min (open flow rate)
|
|
Display items
|
Clock, battery level, operating status
|
|
Display languages
|
English, Cantonese, Czeh, French, German, Italian, Japanese, Korean, Mandarin, Polish, Portuguese, Russian, Slovak, Spanish, Turkish, Vietnamese
|
|
Buzzer volume
|
Approx. 95dB (mean value at 30cm from sound source)
|
|
Gas alarm indication
|
Lamp flashing, continuous modulating buzzer sounding, gas concentration readout blinking
|
|
Gas alarm pattern
|
Self-latching, auto reset
|
|
Fault alarm/ selfdiagnosis
|
Flow abnormality, system abnormality, sensor abnormality, low battery voltage, calibration failure, clock abnormality
|
|
Fault alarm icon
|
Lamp flashing, intermittent buzzer sounding, detail display
|
|
Fault alarm pattern
|
Self-latching
|
|
Communication
specifications
|
USB 2.0 Type-C (for data logger/setting), Bluetooth 4.2 (Bluetooth Low Energy)
|
|
Power source
|
Dedicated Lithium-Ion battery unit (BUL-9000) or dedicated dry battery unit (AA alkaline batteries x 6) (BUD-9000)
|
|
Continuous operating time *1
|
Lithium-Ion battery unit: approx. 25 hours
Dry battery unit: approx. 12 hours (at 25 °C, no alarm, no lighting)
|
|
Operating temperature range *2
|
Approx. 15-minute temporary use environment: -40°C to +60°C (no sudden changes) Continuous use environment: -20°C to +50°C (no sudden changes)
|
|
Operating humidity range*2
|
Approx. 15-minute temporary use environment: 0 %RH to 90 %RH (no condensation) Continuous use environment: 10 %RH to 90 %RH (no condensation)
|
|
Operating pressure range
|
80 kPa to 120 kPa (80 kPa to 110 kPa for explosion-proof range)
|
|
Construction
|
Dustproof, waterproof construction equivalent to IP66/68*3, drop resistant to 1.5m
|
|
Explosion-proof construction
|
Intrinsically safe explosion-proof construction, flame-proof enclosures (with new ceramic type sensor) Intrinsically safe explosion-proof construction (without new ceramic type sensor)
|
|
Explosion-proof class
|
IECEx *4 ATEX*4 Japan EX
Ex da ia IIC T4 Ga II 1 G Ex da ia IIC T4 Ga Ex da ia IIC T4 Ga
(with new ceramic type sensor) (with new ceramic type sensor) (with new ceramic type sensor) Ex ia IIC T4 Ga II 1 G Ex ia IIC T4 Ga Ex ia IIC T4 Ga (without new ceramic type sensor) (without new ceramic type sensor) (without new ceramic type sensor)
|
